Casting structure assures machanical strength.
Adjustable cutting speed from 0 degree to 45 degree.
Saw bow with spring structure
Full blade cover provides more safety.
3 steps belt speeds allows different cutting speed.
Convenient switch for easy operation.
Compact size for easy moving.
Instantly changed from horizontal to vertical cutting.
With standard blade and length stop set
| CUTTING CAPACITY | ||
| 0° |  | 300mm (11.8") |
 | 300 x 432mm (11.8" x 17") | |
 | 300 x 300mm (11.8" x 11.8") | |
| 45° | | 300mm (11.8") |
| 203 x 300mm (8" x 11.8") | |
| 255 x 255mm (10" x 10") | |
| tem | Unit | BS300R |
| Main Motor | HP | 3 (2.2kw)(3-Phase) |
| Speed | Mt/min | 60HZ / 86, 157, 228, 330 (Optional Variable Speed 22-84) |
| Ft/min | 60HZ / 72~275 86, 157, 228, 330 | |
| Saw Blade | mm (WxTxL) | 34 x 1.1 x 3950 |
| inch (WxTxL) | 1-3/8" x 0.043 x 155.5 | |
| Machine Dimensions | mm (LxWxH) | 2100 x 1140 x 1520 |
| inch (LxWxH) | 82.6 x 44.9 x 59.8 | |
| Weight | NW/GW | 740 / 800 kgs |
| Packing Dimensions | mm (LxWxH) | 1940 x 1140 x 1530 |
| inch (LxWxH) | 76.4 x 44.8 x 60.3 | |
| No.of Machines Packed in 20" container | 20' | 6 sets |
| 40' | 12 sets |
