Casting structure assures machanical strength.
Fully adjustable hydraulic downfeed controls the rate of descent
Full blade cover provides more safety.
Gear drive system provides speed changing when saw blade is in unload running.
Bearing carbide guide enhances cutting stability and extends the blade life.
Cutting angle from 0 degree to 45 degree.
Stand jointed with water pan for collecting chip and water
Coolant system for wet cutting.
With Bi-metal blade, chip brush and length stop set
Wheel kit for convenient moving to various work stations
UTTING CAPACITY | ||
0° | ![]() | 229 mm ( 9" ) |
![]() | 178 x 305 mm ( 7" x 12" ) | |
45° | ![]() | 150 mm ( 6" ) |
![]() | 127 x 150 mm ( 5" x 6" ) |
Item | Unit | BS912G |
Main Motor | HP | 1 |
Speed | Mt/min | 60HZ / 45-66-86 |
50HZ / 38-55-72 | ||
Ft/min | 60HZ / 148-216-282 | |
50HZ / 125-180-236 | ||
Saw Blade | mm (WxTxL) | 27 x 0.9 x 2655 |
inch (WxTxL) | 1.06 x 0.035 x 104.5 | |
Machine Dimensions | mm (LxWxH) | 1325 x 630 x 1080 |
inch (LxWxH) | 52 x 25 x 43 | |
Weight | NW/GW | 175 / 205 kgs |
Packing Dimensions | mm (LxWxH) | 1473 x 508 x 1270 |
inch (LxWxH) | 58 x 20 x 50 | |
No.of Machines Packed in 20" container | 20' | 14 sets |
