Products
Casting structure assures machanical strength.
Adjustable cutting speed from 0 degree to 45 degree.
Saw bow with spring structure
Full blade cover provides more safety.
3 steps belt speeds allows different cutting speed.
Convenient switch for easy operation.
Compact size for easy moving.
Instantly changed from horizontal to vertical cutting.
With standard blade and length s
| CUTTING CAPACITY | ||
| 0° |  | 128mm ( 5" ) |
 | 115 x 150 mm ( 4 1/2 " x 6" ) | |
| 45° | | 76mm ( 3" ) |
| 76 x 115 mm ( 3" x 4 1/2" ) | |
| Item | Unit | BS128 |
| Main Motor | HP | 1/3 |
| Speed | Mt/min | 60HZ / 24-37-61 |
| 50HZ / 20-29-50 | ||
| Ft/min | 60HZ / 80-120-200 | |
| 50HZ / 65-95-165 | ||
| Saw Blade | mm (WxTxL) | 12.7 x 0.65 x 1635 W / carbon |
| inch (WxTxL) | 0.5 x 0.025 x 64.37 | |
| Machine Dimensions | mm (LxWxH) | 895 x 457 x 985 |
| inch (LxWxH) | 35.24 x 17.99 x 38.78 | |
| Weight | NW/GW | 60 / 61 kgs |
| Packing Dimensions | mm (LxWxH) | 965 x 330 x 381 (CE 991 x 381 x 406) |
| inch (LxWxH) | 38 x 13 x 15 (CE39 x 15 x 16) | |
No.of Machines Packed in 20" container | 20' | 249 sets (CE190 set) |
