| CUTTING CAPACITY | ||
| 0° |  | 225 mm ( 8 3/4" ) |
 | 240 x 160 mm { 9 3/8" x 6 1/4" ) | |
 | 200 x 200 mm ( 7 7/8" x 7 7/8" ) | |
| -45° | | 160 mm ( 6 1/4") |
| 155 x 115 mm ( 6 1/8" x 4 1/2" ) | |
| 140 x 140 mm ( 5 1/2" x 5 1/2" ) | |
| -60° | | 90 mm ( 3 1/2" ) |
| 90 x 100 mm ( 3 1/2" x 3 7/8" ) | |
| 90x 90 mm ( 3 1/2" x 3 1/2" ) | |
| Item | Unit | BS270 / BS270V | |
| Horse Power | HP | 1.5 (1-Phase) | 1.5 (3-Phase) |
| Feedrate | Mt/min | 60HZ / 106 | 60HZ / 42-84 |
| 50HZ / 88 | 50HZ / 35-70 | ||
| Ft/min | 60HZ / 347 | 60HZ / 138-276 | |
| 50HZ / 289 | 50HZ / 115-230 | ||
| Saw | mm (WxTxL) | 27 x 0.9 x 2450 | |
| inch (WxTxL) | 1.06 x 0.035 x 96.46 | ||
| Machine Dimensions | mm (LxWxH) | 1350 x 700 x 1326 | |
| inch (LxWxH) | 53.15 x 27.56 x 52.2 | ||
| Weight | NW/GW | 220 / 240 kgs | |
| 485 / 529 lbs | |||
| Packing Dimensions | mm (LxWxH) | 1494 x 787 x 978 | |
| inch (LxWxH) | 58.8 x 31 x 38.5 | ||
| No. of Machines Packed in 20” container | 20' | 26 sets / SKD 38 sets | |
