Products
| CUTTING CAPACITY | ||
| 0° |  | 225 mm ( 8 3/4" ) |
 | 240 x 160 mm { 9 3/8" x 6 1/4" ) | |
 | 200 x 200 mm ( 7 7/8" x 7 7/8" ) | |
| -45° | | 160 mm ( 6 1/4") |
| 155 x 115 mm ( 6 1/8" x 4 1/2" ) | |
| 140 x 140 mm ( 5 1/2" x 5 1/2" ) | |
| -60° | | 90 mm ( 3 1/2" ) |
| 90 x 100 mm ( 3 1/2" x 3 7/8" ) | |
| 90x 90 mm ( 3 1/2" x 3 1/2" ) | |
Item | Unit | BS270S | |
| Horse Power | HP | 1.5 (1-Phase) | 1.5 (3-Phase) |
| Feedrate | Mt/min | 60HZ / 106 | 60HZ / 42-84 |
| 50HZ / 88 | 50HZ / 35-70 | ||
| Ft/min | 60HZ / 347 | 60HZ / 138-276 | |
| 50HZ / 289 | 50HZ / 115-230 | ||
| Saw | mm (WxTxL) | 27 x 0.9 x 2450 | |
| inch (WxTxL) | 1.06 x 0.035 x 96.46 | ||
| Machine Dimensions | mm (LxWxH) | 1420 x 510 x 1380 | |
| inch (LxWxH) | 56 x 20 x 54.3 | ||
| Weight | NW/GW | 205 / 225 kgs | |
| 452 / 496 lbs | |||
| Packing Dimensions | mm (LxWxH) | 1300 x 640 x 950 (SKD 1283 x 737 x 673) | |
| inch (LxWxH) | 51 x 25 x 37.5 (SKD 50.5 x 29 x 26.5) | ||
| No.of Machines Packed in 20" container | 20' | 26 sets / SKD38 sets | |
