Products
| CUTTING CAPACITY | ||
| 0° |  | 180 mm ( 7" ) |
 | 200 x150 mm( 7 7/8" x 5 7/8" ) | |
 | 180 x180 mm( 7 " x 7 " ) | |
| -45° | | 115 mm ( 4 1/2") |
| 125 x 110 mm ( 4 7/8" x 4 5/16" ) | |
| 110 x 110 mm ( 4 5/16" x 4 5/16" ) | |
| -60° | | 70 mm ( 2 3/4" ) |
| 70 x70 mm (2 3/4" x 2 3/4" ) | |
| 70 x70 mm (2 3/4" x 2 3/4" ) | |
| Item | Unit | BS210S | |
| Horse Power | HP | 1 (1-Phase) | 1 (3-Phase) |
| Feedrate | Mt/min | 60HZ / 95 | 60HZ / 48-96 |
| 50HZ / 80 | 50HZ / 40-80 | ||
| Ft/min | 60HZ / 310 | 60HZ / 157-314 | |
| 50HZ / 260 | 50HZ / 130-260 | ||
| Saw | mm (WxTxL) | 20 x 0.9 x 2085 | |
| inch (WxTxL) | 0.8 x 0.035 x 82.1 | ||
| Machine Dimensions | mm (LxWxH) | 1280 x 510 x 1370 | |
| inch (LxWxH) | 50.4 x 20 x 54 | ||
| Weight | NW/GW | 180 / 200 kgs | |
| 397 / 441 lbs | |||
| Packing Dimensions | mm (LxWxH) | 1155 x 720 x 925 (SKD 1130 x 584 x 673) | |
| inch (LxWxH) | 45.5 x 28.5 x 36.4 (SKD 45.5 x 23 x 26.5) | ||
No.of Machines Packed
in 20" container | 20' | 30 sets / SKD 54 sets | |
RINO Machinery Industrial Co.,Ltd.
Tel: +86(0)514 8778 4693
Fax: +86(0)514 8778 4695
Add: 433# JiangyangRoad,Yangzhou,Jiangsu,China
