| WORKING CAPACITY | ||
In Mild Steel
| Drilling | 32mm (1 1/4") |
| Face Mill | 76mm(3") | |
| End Mill | 20mm(3/4") | |
| (Optional) | Tapping | 16mm(5/8") |
| In Light Allioy | 32mm(1 1/4") | |
| Item | Unit | BF35 | |
| Main Motor | HP | 1.5 | |
| Speed | 1 Speed Motor (standard) | rpm | 60Hz 340~3000 50Hz 300~2600 |
| 2 Speed Motor (optional) | rpm | 60Hz 170~3000 50Hz 145~2600 | |
| Taper | MT3 | ||
| Stroke | mm | 130 | |
| Travel of Spindle Head | mm | 380 | |
| Dimension of Base | mm | - | |
| Table Size | mm | 550 x 500 | |
| Column Diameter | mm | Ø115 | |
| T-slots Size | mm | 16 x 26 | |
| Cross Travel | mm | 380 | |
| Packing Dimensions | mm(L x W x H) | 610 x 890 x 160 (Machine) 965 x 800 x 203 (Stand) | |
| Machine Weight | NW/GW | 250 / 280 kgs (Machine) 35 / 36 kgs (Stand) | |
| No. of Machines Packed in 20” container | 20' | 36 sets (with stand) 52 sets (w / o stand) | |
