Products
| WORKING CAPACITY | ||
| In Mild Steel | Drilling | 28mm (1 1/8") |
| Tapping (Optional) | 16mm (5/8") | |
| Item | Unit | B30 | |
| Main Motor | HP | 1 (1 or 3-Phase) | |
| Speed | 1 Speed Motor (standard) | rpm | 60Hz 140~2600 50Hz 115~2165 |
| 2 Speed Motor (optional) | rpm | - | |
| Taper | MT3 | ||
| Depth | mm | 120 | |
| Table Size | mm | 420 x 470 300 x 350 (Optional swivel vise table) | |
| X Travel | mm | 250 | |
| Y Travel | mm | - | |
| Column Diameter | mm | - | |
| No. of T Slot | mm | Ø100 | |
| T Slot Size | mm | 2 | |
| Packing Dimensions | mm(L x W x H) | 905 x 740 x 1875 | |
| Machine Weight | NW/GW | 200 / 230 kgs | |
| No. of Machines Packed in 20” container | 20' | 18 sets | |
