Products
Digital Readout of Spindle Travel.
Working Lamp.
| Item | Unit | BF16 | |
| Drill Capacity in Steel | mm | 16 | |
| Face Mill Capacity Max. | mm | 50 | |
| End Mill Capacity Max. | mm | 16 | |
| Main Motor | KW | 0.5 | |
| Spindle Speed Stepless | rpm | 50-1125 / 100-2250 | |
| Spindle Taper | MT2 | ||
| Mill head tiltable | -90° to +90° | ||
| Stroke | mm | 50 | |
| Depth Spindle to Column | mm | 170 | |
| Table Size | mm | 500 x 140 | |
| X Travel | mm | 365 | |
| Y Travel | mm | 140 | |
| Distance spindle to table | mm | 275 | |
| No. of T Slot | 3 | ||
| T Slot Size | mm | 10 | |
| Packing Dimensions | mm (L x W x H) | 640 x 550 x 850 (w/o stand) | |
| Machine Weight | NW/GW | 60/ 70 kgs | |
Cabinet Stand
Coolant System
Worktable Power Feed
Worktable Lubrication Pump
