| Drilling Capacity in Cast Iron | OD-18mm |
| Drilling Capacity in Steel | OD-15mm |
| Capacity face milling | OD-75mm/2.5mm |
| Capacity end milling | OD-20mm/6mm |
| Spindle Taper | R8/NT- 30 |
| Diameter of Quill | 85mm |
| Number of Spindle Speeds | Variable |
| Range of Spindle Speeds (50HZ) | 0-4,500 rpm |
| Range of Spindle Speeds (60HZ) | 0-4,500 rpm |
| Power Down Feed per Revolutions of Spindle | 0.04/0.08/0.15mm/rev. |
| Number of Power Feeds | 3 |
| Spindle Travel | 127mm |
| Head Movement (L to R) | 90 degrees |
| Head Tilt | 45 degrees |
| Max. Distance Spindle to Table | 50-400mm |
| Max. Distance Spindle to Column | 630mm |
| Min. Distance Spindle to Column | 250mm |
| Collet Capacity | 3mm-16mm |
| Size of Table | 252mmx1115mm |
| Longitudinal Table Travel / X-Axis | 600mm |
| Cross Table Travel / Y-Axis | 380mm |
| Number of T-Slots | 3 |
| T-Slot Size | 16mm |
| T-Slot Centers | 64mm |
| Max. Weight of Workpiece | 380kg |
| Travel of Knee | 406mm |
| Overarm Travel | 320mm |
| Overall Dimensions Wx Dx H | 1570x1560x2200mm |
| Horse Power for Main Motor | 2.2kw (3HP) |
| Shipping Weight (approx.) | 1262kg |
| Control Switch Box w/Rotary Arm |
| With Chip Tray on Base |
| Coolant Pump System |
| Levels and pads included |
| 24V Work Lamp System |
| Turcide-B for X/Y axis movement. |
| Air Power Draw Bar |
| CE Spindle Guard Accessory |
| X axis table power feeder |
