Products
| Centers height | 160mm |
| Max swing over the bed | 320mm |
| Max swing over the cross slide | 198mm |
| Max swing over the gap | 476mm |
| Distance between centers | 1000m |
| Spindle taper | MT5 |
| Spindle bore | 38 |
| Spindle nose Camlock | Camlock D1-4 |
| Spindle speeds | (18)65-1950rpm |
| Bed width | 180mm |
Longitudinal feeds | 0.052-1.392mm/rev |
| Cross feeds | 0.009-0.253mm/rev |
Metric threads | 0.4-7mm |
Inch threads | 4-56TPI |
| Tailstock taper | MT3 |
| Tailstock sleeve diameter | 32mm |
| Travel of tailstock sleeve | 100mm |
| Three-phase motor | 1.5KW/400V/50HZ |
| NW/GW | 615/500KG |
Over dimensions | 1960 x 750 x 1430 mm |
| Package size | 1980 x 760 x 1450 mm |
3+3 jaw self centering chuck Ø 200 mm
4 Reversible indipendent jaws chuck Ø 200 mm
Dead center MT 5
Dead center MT 3
Live center MT 3
Reduction sleeve MT 5/3
Face plate Ø 250 mm
Follow rest
Steady rest
Foot brake
Thread dial
Leadscrew hood
Chuck safeguard
Full length splash guard
T0AE quick change tool post
Working lamp
