Products
| Centers height | 140mm |
| Max swing over the bed | 280mm |
| Max swing over the cross slide | 170mm |
| Max length of workpiece | 700mm |
| Spindle taper | MT5 |
| Spindle bore | 38mm |
| Spindle speeds | (6)50-850rpm/110-1800rpm |
| Bed width | 180mm |
Longitudinal feeds | 0.07-0.65mm/rev |
| Cross feeds | 0.03-0.12mm/rev |
Metric threads | 0.2-3.5mm |
Inch threads | 8-56TPI |
| Tailstock taper | MT2 |
| Travel of tailstock sleeve | 85mm |
| Single-phase motor | 0.85KW/230V/50HZ |
| NW/GW | 300/335KG |
Over dimensions | 1129 x 690 x 1127 mm |
| Package size | 1229 x 720 x 1227 mm |
3+3 jaw self centering chuck Ø 125 mm
4 Reversible indipendent jaws chuck Ø 125 mm
Type C quick change mount
Dead center MT 5
Dead center MT 3
Face plate Ø 240 mm
Follow rest
Steady rest
Leadscrew hood
Chuck safeguard
Full length splash guard
Saddle gears in oil
Thread dial
4 side fix tool post 12 mm
Quick stop tailstock with a swing of 85 mm
